Roof and Wall Cladding Sheet Roll Forming Machine
Our metal sheet roll forming machine can be available to produce the sheets which are used as roof panels or wall cladding sheets.
There are innumerable sheet profiles used as roof panels or wall cladding sheets or metal facade panels in each corner of the world, and each profile will required one roll forming machine at least one roll forming unit. Some times the roof panels can be used as wall cladding sheets as well, so the roof and wall cladding roll forming machine has been built accordinly and this roof panel roll forming machine or wall cladding sheet roll forming machine is what customers really need. Another case is when clients don’t know what profiles are the most suitable for them, we usually recommend a roof and wall cladding roll forming machine because the final metal sheets can be applied both as roof panels and wall cladding sheets.
- Meishun
- Xiamen
- 30-50 days
- 100 sets/annual
- Information
Roof & Wall Cladding Sheet Roll Forming Machine
Roof and Wall Cladding Roll Forming Machine is used for both metal roofing panels and wall cladding sheet's production.
It consists of one set decoiler, materials guiding device, main roll forming mill, PLC Control System, Hydraulic cutting, final products collect table.
The advantage of this roof & wall cladding sheet roll forming machine is, you could produce roofing sheet and wall cladding sheet if you don't have special design on the panels.
Meishun with 30+ years experience on the metal roll forming machine's design & manufacture, with our invention panted. We could do customize machine for you.
| Equipment Parameters | |
| Equipment Name: | MS30-150-750 roll forming machine |
| Forming Passes: | 17 groups roller |
| Equipment Components: | Decoiler - Manual Tenso Shearing - Main Roll Forming Mill - Forming Cutting Device - Hydraulic Station - FLC Control Cabinet - Final Products Rack |
| Equipment Size (L x W x H) | 7.5m x 1.5m x 1.2m |
| Main Motor Power | 5.5KW |
| Hydraulic Motor Power | 3KW |
| Equipment Total Weight | Approx. 7 tons |
| Feeding Material Width | 1000mm |
MEI SHUN Roof and Wall Cladding roll forming machine produced by our factory has the advantages of fast speed, high efficiency and stable operation, which meets the requirement of our customers in the building industry.
MEI SHUN Roof and Wall Cladding Roll Forming Machines can be design and produce various kinds of roof and wall panel. Our engineers with 30 years’ experience will satisfy well your requirement.
Fast running speed and wide application range. Easy maintenance.
High production precision and convenient operation: advanced PLC and touch screen control system are adopted.
The machine has long service life and reasonable structure.
Superior performance. Energy saving and environmental protection.
The transmission structure receives orders. Smooth operation.
Measurement: high performance servo control system is adopted to ensure production accuracy.
The structural parts are optimized by computer finite element analysis to ensure that the structural parts are firm and durable. The hydraulic system is well synchronized with the transmission system.
